Profile Options
Omniplate 1500
Omniplate 1500
Omniplate 1500 is an economical barrier wall system that acts as the primary weather barrier for a building using visible caulk joints. Made from aluminum or stainless steel plate, it offers broad design freedom—including curves, complex 3D profiles, and seamless transitions without exposed trim. It mounts with concealed fasteners over various substrates, making it well-suited for walls, canopies, soffits, and column enclosures.
Aluminum: .125, .090, .188, & .25
Stainless Steel: 14, 16, & 12 ga.
Widths: 12” to 65” *
Lengths: 12” to 160” *
Depth: 1.75” minimum
* Maximum panel size depends upon plate material, gauge, finish, and geometry.
12″
160″
1.75” minimum
Flat
Curved
Custom 3D profiles
Yes
Aluminum: 70% PVDF
#4, #6, #8, and non-directional finishes for stainless plate
Choice of over 40 stock colors
Custom colors and finishes available*
Optional: Contact ATAS for specifying
A complete line of trims available in matching colors, gauge, and finish or as specified
Details provided allow for typical expansion and contraction values of the metal cladding materials as provided by ATAS International, Inc only. Allowance must be made for additional sub-structure movement based upon materials used and overall project design.
