The Multi-Purpose™ panels with the Wind-Lok® interlock have a smooth but sleek appearance with a concealed clipless fastening system. This interlock also allows the Multi-Purpose™ panels to be combined with Corra-Lok™, Metafor™, and Rigid Wall II™ for the ability to create interesting patterns and breaks. Typical applications include walls, fascias, mansards, equipment screens and some limited roofing with a minimum slope of 3:12.
You can also enhance aesthetics of Multi-Purpose™ by using factory fabricated Elite Series accessories, including the Z Box and Closure Angle.
SKU:
- MPN, MPW, MPV, MPH, MPS
Material:
- .032, .040 aluminum
- 24, 22* ga. metallic coated steel
- 16, 20 oz. copper*
- .8, 1.0 mm zinc*
- .0197 classic & tin matte stainless steel*
- (MPS: .032 aluminum)
Panel Coverage:
- 8″, 12″ and 16″
Panel Depth:
- 1¼”
- ⅜” (MPS)
Minimum Length:
- 3’-0”
Texture:
- Smooth
- Stucco Embossed
- Wood Grain Embossed (24 ga. metallic coated steel, .032 aluminum & .040 aluminum only)
Perforations Available: yes
Colors:
- Choice of over 40 stock colors
- Custom colors and finishes available*
*Subject to minimum quantities and extended lead time. Inquire for material and panel coverage availability
